Hi-Tech Butterfly Valves India Pvt. Ltd.

Integrally Cast Mounting pad provides direct mounting of many actuators as per ISO 5211.
Flattened body bore at stem journal ports positions stem bearing near disc, providing maximum stem support
Disc taper pins are tangentially positioned half on disc and half in stem,which eliminates potential of failure. Special Positive locking arrangement can also be provided if asked / as per customer need.
Integrally cast disc position stop perfectly locates the disc in seat, achieving maximum seat and seal life.

Size Range	Class
2" - 72"	PN 2.5/ PN 6/PN 10/PN 16/Class 150
End Connection	Flanged / Lug / Wafer
Operation	Lever, Gear Operator, Electrical Actuator, Pneumatic Actuator.

Design Standard	AWWA C 504, API 609, BS 5155, IS 13095, ASME B 16.34, IS 13095
Testing Standard	API 598 / BS 6755 I / BS EN 12266-1
Face To Face	AWWA C 504, API 609, BS 5155, IS 13095 , ASME B 16.34, IS 13095
End Connection	ANSI B 16.5, BS 10 Table, AWWA C 207, IS 6392, ASME B 16.47, etc.

Operator	Size Range
Lever :	2"- 6" - PN 6/PN 10/PN 16/Class 150
Gear Operator :	6" Above - PN 6/PN 10/PN 16/Class 150

Shell	WCB, CF8, CF8M, CF3, CF3M, CF8C, CN7M, CD4MCu, Hastelloy, Inconel, Duplex Stainless Steel
Trim	WCB, CF8, CF8M, CF3, CF3M, CF8C, CN7M, CD4MCu, Hastelloy, Inconel, Duplex Stainless Steel
